The TIG-200CL TIG Welding Machine is an industrial-grade tool crafted for both professional and domestic use, offering affordable yet exceptional welding capabilities. With its compact design and lightweight construction, this machine is perfect for home workshops or light industrial applications.
Operating seamlessly on a standard 220V input voltage with a frequency of 50/60 Hz, this welding marvel boasts a compact design, measuring at 365mm x 160mm x 305mm and weighing just 7kgs. Its lightweight and compact dimensions make it effortlessly portable and convenient for transportation and storage, ideal for on-the-go welding tasks.
Featuring a broad current range spanning from 20A to 220A, the TIG-200CL TIG Welding Machine offers versatility in welding various materials with unmatched finesse. From delicate stainless steel to rugged carbon steel, this machine handles each weld with precision and accuracy.
Equipped with a user-friendly control interface, this welding machine simplifies the welding process, enabling both novices and seasoned welders to achieve outstanding results effortlessly. The maximum no-load voltage of 65V ensures safety and stability during operation, providing peace of mind to the welder.
Whether you're a beginner venturing into the world of welding or a professional seeking a reliable tool for intricate projects, the TIG-200CL TIG Welding Machine is the ultimate choice. With its robust performance, ease of use, and steadfast reliability, it's a must-have addition to any welding arsenal.
ACCESSORIES:
| MODEL / ITEM | TIG-200CL | TIG-220CL |
| Input Voltage(V) | 1PH220V | 1PH220V |
| Frequencu(Hz) | 50/60 | 50/60 |
| Rated Input Capacity(KVA) | 7.2 | 8.6 |
| NO-load Voltage(V) | 60 | 60 |
| Current Range(A) | 10-200 | 10-220 |
| Rated Duty Cycle(%) | 60 | 60 |
| Usable Electrode(mm) | 1.6-3.2 | 1.6-3.2 |
| Insulation Class | F | F |
| Efficiency(%) | 85 | 85 |
| Power Factor | Cosφ0.93 | Cosφ0.93 |
| Proterction Degree | IP21S | IP21S |
| Dimension(mm) | 365x160x305 | 365x160x305 |
| Weight(kg) | 7 | 7.2 |
